Safe Control Under Uncertainty

Designing provably correct controllers for dynamical control systems under uncertainty.

In today’s world, more and more autonomous systems operate in safety-critical settings. These systems must accomplish their task safely without the intervention of a human operator. For example, consider a unmanned aerial vehicle (UAV) whose task is to deliver a package to a designated target area. The UAV should not crash into obstacles, nor should it run out of battery. In other words, the drone must behave safely.

However, turbulence or wind gusts may cause uncertainty in the position and velocity of the UAV. Such factors, also referred to as noise, render the behavior of the UAV uncertain. Consequently, the ambitious aim is to compute a controller for the UAV, such that it progresses safely to its target, despite the uncertainty. The focus of our research group is such dependable and safe decision-making under uncertainty. AI systems, such as the UAV, need to account for the inherent uncertainty in the real world autonomously. We combine state-of-the-art techniques from machine learning, artificial intelligence, control theory, and rigorous formal verification to provide strong guarantees on the safe decision-making of AI systems.

Abstraction-based planning

Given a continuous-state, continuous-action dynamical system with uncertainty, the general problem that we face is to compute a feedback controller that maximizes the probability to satisfy a complex specification, such as reaching a desired goal state while avoiding unsafe states. This problem is very hard to solve in general, because the state and control inputs are continuous, and because the outcomes of control inputs are uncertain due to disturbances in the form of noise.

The key step in our approach is to compute a discrete-state abstraction of the continuous system. Loosely speaking, we partition the infinitely many states into a set of abstract, discrete regions. We then define abstract actions that correspond to control inputs that cause transitions between these regions. Depending on the type of uncertainty about the system dynamics, the outcome of every action is either stochastic or even nondeterministic. Our abstraction procedure ensures that we obtain a faithful, yet abstract representation of the dynamical system as a type of Markov decision process.

Solving the UAV delivery problem

Now consider the specific UAV delivery problem in Figure 2, with the target area in green, and the obstacles that we must avoid in red. With our method, we can compute a controller, for which the probability to safely reach the target area is above a predefined safety threshold. The effect of turbulence causes a non-Gaussian stochastic disturbance that affects the 6-dimensional state of the UAV. The wind strength may vary from day to day, so the optimal path to take may differ as well. With our method, we can take this effect into account, because we reason over the effect of the turbulence explicitly. As shown in the figure, under weak turbulence, the UAV takes the short but narrow path, while under high noise, it is safer to take the longer path around the obstacles. Thus, accounting for noise is important to obtain controllers that are safe.

Simulated trajectories for the UAV under different turbulence conditions. Left: weak turbulence. Right: strong turbulence.

Related publications

  1. Sampling-Based Robust Control of Autonomous Systems with Non-Gaussian Noise
    In AAAI (distinguished paper) 2022
    ​ ​
  2. Probabilities Are Not Enough: Formal Controller Synthesis for Stochastic Dynamical Models with Epistemic Uncertainty
    Thom BadingsLicio RomaoAlessandro Abate, and Nils Jansen
    In AAAI 2023
    ​ ​
  3. Robust Control for Dynamical Systems with Non-Gaussian Noise via Formal Abstractions
    Journal of Artificial Intelligence Research 2023
    ​ ​
